Loading unloading Gravity Roller Conveyor
The gravity steel roller conveyor adopts an adjustable movable bracket. When the bracket forms a certain height difference and inclination angle, the goods can slide on it.
Small space occupied
Adjustable height
Modular design, 360 degree turn
Cost-effective, energy -effective
Easy to instal, less maintainance
Solid and durable, long period service time
| Drive mode | Gravity |
| Width | 500/600/800/1000/1200mm |
| Expandable Length / unit | 1000mm /1250mm /1500mm |
| shorten length /unit | 530mm |
| Roller Dia. | 50mm |
| Pitch Size | 60/80/110mm |
| Central distance | 110/140/160mm |
| Roller thickness | >=1.2mm |
| Adjustable height | 450-650mm 570-850mm 750-1100mm optional or customized |
| Material of roller | Carbon steel /stainless steel 201/304 as customized |
| Material of Frame | Carbon steel or as customized |
| Caster | all purpose caster with safety brake |
Packaging Detail: inner by PE film winding then wooden box packing
Delivery Detail: According to order quantity
1.Suitable for indoor environment
2.Suitable for transportation of box goods with flat bottom in various industries,such as Packing industry,Express industry,Tire industry, Pharmaceuticals industry, Furniture industry,Tobacco industry, Warehousing,logistic, Food industry, Super market, etc.
1. OEM &ODM Service
2. Special conveyor or other related machines' customer-made
3. Design for buyer
